Tyvek StructureGuard Rainscreen Cladding Breather Membrane 2.7m X 100m

DuPont Tyvek StructureGuard is a wall cladding membrane and the
professional choice for exceptional protection, improved durability and
energy efficiency especially in commercial buildings.

Properties

Length: 100m.
Width: 2.7m.
Roll size: 270m2.
UV exposure: 4 months.
Warranty: 10 years.
Certification: BBA certified.

Installation

Fixing to timber studs/sheathing
Fix
Tyvek StructureGuard with stainless steel staples or corrosion
resistant nails. Fix at max 600mm centres horizontally and 300mm centres
vertically. Fix membrane at max 150mm centres at joints and openings.

Fixing to insulation
Fix
Tyvek StructureGuard to rigid insulation with a proprietary expanding
insulation fixing anchor. In cladding applications timber battens or
metal brackets may also be used to fix the membrane.

Fixing to steelwork
Fix
Tyvek StructureGuard to steelwork with an appropriate fixing system
such as a 25mm Steel Framing Screw with an EPDM rubber washer

Fixing to masonry
Fix Tyvek StructureGuard to masonry with an anchor fixing system or masonry nail and EPDM rubber washer.

Features

• Good airtightness for energy efficiency and Part L compliance.
• Highly water resistant, exceeding W1 (1.5m water head) standard, even after ageing.
• Exceptional long-term durability and UV resistance (tested to 4 months UV exposure).
• Can be used in all  wall constructions including commercial and residential.
• Wind-tight – protecting insulation performance.
• Strong, lightweight and flexible for easy site installation.
• 10 year limited product warranty.
• Good nail tear resistance.
• Malleable, Fabric Feel.
